ເຄື່ອງຕັດໂລຫະສະແຕນເລດເຫຼັກເສັ້ນສະແຕນເລດທີ່ມີຄວາມແມ່ນຍໍາສູງ 1000w

ລາຍລະອຽດຂອງສິນຄ້າ


Certification: CE FDA ISO9001
Model Number: RL-PT3015-1000
ເງື່ອນໄຂການຈ່າຍເງິນແລະຂົນສົ່ງ:
ຈຳ ນວນສັ່ງຊື້ຂັ້ນຕ່ ຳ: 1 ຊຸດ
ລາຄາ: ໂດລາສະຫະ
Packaging Details: Wooden Box
ເວລາສົ່ງສິນຄ້າ: 30-45 ວັນ
Payment Terms: D/A, D/P, L/C, Western Union, T/T, MoneyGram
Supply Ability: 100 SETS PER MONTH

ລາຍລະອຽດຂອງສິນຄ້າ


Model NO.:RL-PT3015-1000ຊື່:ເຄື່ອງຕັດເສັ້ນໃຍແກ້ວ
ເງື່ອນໄຂ:ໃຫມ່Guide Rails:Taiwan Hi-Win Square Guide
Fiber Laser Cutting Head:USA Lasermechຄວາມໄວຕັດ:ປັບໄດ້
Floor Space:5.6m X 3.2mປະເພດເລເຊີ:Max, Raycus, IPG
ລະບົບຄວບຄຸມ:Professional Laser Control System--Cypcutລະຫັດ HS:8456110090

ລັກສະນະຕົ້ນຕໍ


1. Superb quality of laser beam, constant BPP within all the ranges of laser powers,so that long focus can still get pretty small laser spot.
2. Special wavelength(1070nm), having special capability of cutting highly-reflective materials,such as aluminium, cooper and brass,etc.
3. Electro-optical conversion efficiency of laser supply>25%, much more efficient than CO2(<10%), so that consumption of electricity has been depleted very much.
4. Laser is transmitted by fiber cables, almost no consumption during transmission.
5. Modular design, “using immediately after plugging in”, mini size,easy to be installed, no maintenance of laser supply and transmission system of laser beam.
6. Life span of pumping source >100,000 hours.
7. Precise beam quality, with a small divergence Angle
8. Unique design of QCS joint was relieved from the foreign products using QBH joints need to add the deficiencies of the collimating lens, divergence Angle is small, simple maintenance
9. Unparalleled product life
10. Using single cell junction semiconductor pump laser pump sources are used as a fiber laser, fiber laser has the characteristics of long life.
11. Low power consumption, the product maintenance free.
12. Fiber laser has excellent thermal performance, high electro-optical efficiency, water saving electricity saving, especially important is can free maintenance for a long time to use, can save a lot of maintenance funds and time, improve work efficiency.

ໂດຍສະເພາະ


1 The European CE standard production
2 Working area: 1500*3000mm
3 Laser type: Raycus brand in China Fiber laser generator; Raytools laser cutting head.
4 Water-cooling system: water chiller 2P
5 Transmission type: Taiwan Hiwin Rack and pinion.
6 Motor: Japan YASKAWA servo motor driving (X axis 850w, Two Y axis each of them is1800w , Z axis 400w )
7 Control system: Shanghai Cypcut control system
8 Rail: Taiwan PMI square rails
9 Dust hood for X axis and Y axis, and laser head.
10 Cross sliding rack working table.
11 Integrally cast welding machine body, and though many procedures(just like aging treatment, precision milling machine processing etc.).
12 PM2000 software.

ອຸດສາຫະ ກຳ ການສະ ໝັກ


Fiber Laser Cutting Machines are widely used in manufacture Billboard, Advertising, Signs, Signage, Metal Letters, LED Letters, Kitchen Ware, Advertising Letters, Sheet Metal Processing, Metals Components and Parts, Ironware, Chassis, Racks & Cabinets Processing, Metal crafts, metal art ware, elevator panel cutting, hardware, auto parts, Glasses Frame, Electronic Parts, Nameplates, etc

ວັດສະດຸທີ່ໃຊ້ໄດ້


ອຸປະກອນຕັດ laser ເສັ້ນໃຍແມ່ນ ເໝາະ ສົມ ສຳ ລັບການຕັດໂລຫະເຊັ່ນ: ເຫລັກສະແຕນເລດ, ແຜ່ນເຫລໍກອ່ອນ, ແຜ່ນເຫລໍກຄາບອນ, ແຜ່ນເຫຼັກໂລຫະປະສົມ, ແຜ່ນເຫຼັກພາກຮຽນ spring, ແຜ່ນເຫຼັກ, ເຫຼັກທາດເຫຼັກ, ໂລຫະປະດັບ, ແຜ່ນອາລູມິນຽມ, ແຜ່ນທອງແດງ, ແຜ່ນທອງເຫລືອງ, ແຜ່ນເຫລັກ , ແຜ່ນທອງ, ແຜ່ນເງິນ, ແຜ່ນ Titanium, ແຜ່ນໂລຫະ, ແຜ່ນໂລຫະ, ທໍ່ແລະທໍ່, ແລະອື່ນໆ.
